| Execution | KVOP-type A | KVOP Type-B | |
| Degree of protection of the shell |
IP67 |
||
| Operating temperature range |
-60 .. +85°С |
||
| Number of cable entries |
from 1 to 4 |
From 1 to 12 |
|
| Number of terminal connectors |
6 |
24 |
|
| Cross-section of connected wires |
0.08 – 2 mm 2 |
0.08-2.5 mm 2 |
|
| Maximum voltage |
30V |
400 |
|
| Maximum contact current | 0.25A |
50A |
|
| Interior space |
90x90x30mm |
200x105x75mm |
|
| Overall dimensions without cable entries |
100x100x43mm |
220x120x90mm |
|
| Body material |
Polyamide |
||
| Weight, no more than |
0.25 kg |
2 kg |
|
The boxes are supplied with plastic cable entries MG16, MG20, MG25, MG32 of various sizes
