| Orbita VZ Z | Orbita VZ S | Orbita VZ SZ | |
| Operating voltage | 12-30 VDC | 12-30 VDC | 12-30 VDC |
| Input current, max. | 0,15 A | 0,08 A | 0,2 A |
| Orbita VZ Z 220V | Orbita VZ S 220V | Orbita VZ SZ 220V | |
| Operating voltage | 220 VAC | 220 VAC | 220 VAC |
| Input current, max. | 0.04 mA | 0.03 mA | 0.06 mA |
| Explosion protection type and category | 1 Ex mbib llB T4 Gb X | ||
| Ingress protection | IP 65 | ||
| Overall dimensions | 100х100х60 mm | ||
| Sound pressure at 1 m distance, min. | 105 dB | 105 dB | |
| Цвет сигнала | Red (default) Yellow Green White Blue |
Red (default) Yellow Green White Blue |
|
| Weight, max | 1,0 kg | ||
| Operating temperature range | -60°С…+70°C | ||
| Material | Polyamide | ||
Alarm devices is supplied with 1.5 m power cable in metal hose; cable length can be specified by the customer. For easier installation, there is a coupling at the end of the power cable of the alarm that is screwed onto the cable gland of the junction box with G 1/2 thread.
