| Name | Sfera 12-24V (outdoor version) | Sfera 220V (outdoor version) | Sfera ЗУ 12-24V, 220V (outdoor version) | Sfera РИП 12-24V, 220V (outdoor version) |
| Operating voltage | 12-30 VDC | 12-30 VDC | 12-30 VDC | |
| Input current, max. | 0,15 А | 0,25 А | 0,18 А | |
| Operating voltage | 220 VAC | 220 VAC | 220 VAC | |
| Input current, max. | 0,05 А | 0,24 А | 0,24 А | |
| Ingress protection | IP 66 | |||
| Overall dimensions | 385х165х55 mm | |||
| Sign size | Min. 330x80 mm | |||
| Sound pressure at 1 m distance, min. | 105 dB | |||
| Autonomous operation time, min. | 5 hr | |||
| External illumination of text sign without loss of contrast discernibility, max. | 500 lx | |||
| Weight, max. | 2.5 kg | |||
| Temperature range | -60°С...+85°C | |||
| Material | Impact-resistant polyamide | |||
ANNUNCIATOR is supplied with 1.5 m power cable; cable length can be specified by the customer.
